Doors that bind, grind, sag or jump the track, aligned and running true again · (239) 445-4425

(239) 445-4425 Get It Running True
Dark gray garage door set into a brick wall

Lift cable work

Garage Door Cable Repair in Ave Maria

Frayed, slipped or unevenly wound lift cables are replaced in pairs, seated in their drum grooves and drawn to equal tension so the door rises level.

Describe the cable problem — (239) 445-4425

Two Steel Cables Carry the Whole Lift

A lift cable runs from a bracket at the bottom corner of the door, up past the roller and onto a grooved drum at the end of the shaft. As the shaft turns, both cables wind onto their drums in step and lift both corners together. Everything depends on those two cables being the same length, the same tension and seated in their grooves.

When one frays, stretches or jumps its drum, the corners no longer lift as a pair. The door tilts, a roller strains and the other cable carries extra load. Repair replaces both cables, rewinds the drums correctly and sets tension until the bottom edge stays level.

How a Bad Cable Shows Itself

  • Broken wire strands

    Fine strands standing out from the cable, most often near the bottom bracket where rust and bending concentrate, mean the rope is parting wire by wire.

  • Slack loop on one side

    A cable hanging in a loose curve has come off its drum or lost tension, and its corner of the door lags while the other side lifts.

  • A crooked rise

    If the bottom edge visibly tilts partway up, the cables are lifting unequally, and the door will keep stressing the track until they are equalised.

Replacing and Setting the Cables

  1. 01

    Hold the door

    Clamps secure the door and the spring tension is let down in a controlled way first, because the cables are hooked to springs that keep pulling on them.

  2. 02

    Fit new cable

    Both cables are replaced to the correct length for the door height, with ends secured at the bottom brackets and hooked through the drums.

  3. 03

    Seat the drums

    Each cable is wound into its drum groove, the drum fixed to the shaft and tension matched side to side, so neither wire rides over another.

  4. 04

    Check the level

    Lift and lower the door manually with a level resting on its bottom edge, and correct any tilt before the opener is reattached.

Questions About Cables

Is it enough to replace only the frayed cable?
It is better to replace both. They have flexed the same number of times, so the second is close to failing too, and matching new lengths makes it far simpler to keep the lift even on both sides.
Why did my cable come off the drum?
Usually the door was moved while a cable was slack, a bracket or drum shifted, or the cable was already worn. Once off its groove, it can bind against the drum edge, kink and lose strength.
Can I keep running the door with one damaged cable?
No. The remaining cable and the track take uneven load, the door can swing out of the track and a failing cable can part under tension, dropping one corner of a heavy door without any warning.

Cables Should Pull as a Pair

If a cable looks frayed or loose, leave the door alone and describe what you see. It may be simpler than it looks.
